JIVA_XT-8315

JIVA XT Series


The XT-8315 is the companion of the XT-7315, which has been enhanced with 11th Gen Intel® Tiger Lake CPUs, which is powerful enough to handle any task imaginable that comes its way.

Add to Compare

Key Features


  • Sleek Look
  • Powerful and Reliable
  • GEN8E Base
  • Multi-Position Folding Base
  • Fanless Design
Category:

Additional information

System Configuration
Processor

Intel Tiger Lake Core i3-1115G4E, up to 3.90 GHz, 6M Cache;, Intel Tiger Lake Core i5-1145G7E, up to 4.10 GHz, 8M Cache;, Intel Tiger Lake Core i7-1185G7E, up to 4.40 GHz, 12M Cache

Storage Device

M.2 connector [Support both SATAIII signal and PCIe signal] x 2

System Memory

DDR4 SO-DIMM x 2, max. 64 GB

Power Supply

12/150W with optional PoweredUSB and USB Type-C, 12V/84W (default)

Intel vPro Support

Yes, with Core i5 & i7 CPU

RAID Function

YES

TPM Support

Yes, TPM 2.0
Display & Touch
LCD Display

15” TFT LCD

Resolution

1024 x 768

Touch Function

True-flat PCAP touch with multi-touch support (IP65 on front panel)
I/O & Expansion
Audio

Internal 2W speaker x 1 + Line-out/mic-in combo jack

CR Port

1, control 2 CR via optional Y-cable, supporting 24V cash drawer

Display Port

2, VGA x 1, 12V support for Posiflex monitors; HDMI x 1

Extension Slot

M.2 slot x 1

LAN Port

10 / 100 / 1000 Mb x 2

Parallel Port

1, via optional conversion cable through service window

Powered USB Port

Optional 24V x 1 + 12V x 3 via GEN8E base, Optional 24V x 1 in motherboad

PS/2 Port

1, via optional conversion cable through service window

OTG USB

N/A

Serial Port

5, RJ50 x 3 + 2 via optional converter cable from service window, 5V support on all COM ports, 12V support on COM1 to 3 (all converter cables are optional)

Standard USB Port

6, USB 3.0 x 4 + USB 2.0 x 2; Optional USB Type-C port for both storage & display

UPS Port

YES, Battery Optional
Built-in Option
Built-in MSR

N/A

AG Glass

N/A

Camera

N/A

WiFi

M.2 WiFi/BT module
Physical Characteristics
Dimension (W x D x H in mm)

372 x 320 x 252.7

Weight (N.W. in Kg)

5.86
Environment
Operating Condition

0°C – 40°C, 20%RH – 90%RH

Storage Condition

-20°C – 70°C, 10%RH – 90%RH
Attachment Options
Line Display

2 x 20 rear-mount VFD/LCD customer line display;, 7" color LCD graphical customer line display

POS Monitor

Non-touch TFT LCD: 7"/9.7"/12.1"/14"/15";, PCAP touch TFT LCD: 9.7"/14"/15";, Resistive touch TFT LCD: 15"
Jumper Setting
Series Jumper Setting Download
